TP-Link Archer T4E AC1200 Wireless Dual Band PCI Express Adapter
Experience seamless wireless connectivity with the TP-Link Archer T4E AC1200 Wireless Dual Band PCI Express Adapter. This high-performance adapter delivers combined speeds of up to 1200 Mbps across dual bands—867 Mbps on 5GHz and 300 Mbps on 2.4GHz—ensuring smooth streaming, gaming, and browsing. The advanced beamforming technology focuses signal strength directly to your devices for improved range and stability. Easy PCI Express installation makes it compatible with most desktop computers. Perfect for users seeking reliable wireless performance without the need for external antennas. Upgrade your desktop's connectivity today.
- Easy Installation – Plug the adapter into an available PCI-E slot to upgrade your desktop
- High Speed Wi-Fi – Up to 1200 Mbps Wi-Fi speeds (867 Mbps on 5 GHz band and 300 Mpbs on 2.4 GHz band)
-
802.11ac Dual Band – 3 times faster than the 802.11n standard, perfect for high-intensity network usage
-
Beamforming – Wi-Fi signals are strengthened towards certain direction where client exists
-
Multiple-Size Brackets – Low profile and full heigh brackets are both provided, suitable for all PCs
-
2×2 MIMO – Users can easily access to high-speed wireless connection
-
Broad Wireless Range – Two external antennas ensure greater Wi-Fi coverage and enhanced stability
Specifications
| Interface | PCI Express |
|---|---|
| Dimensions ( W x D x H ) | 4.8 x 4.5 x 0.85 in (120.8*115.2*21.5 mm) |
| Antenna | 2 Dual Band Detachable Antennas |
| Standards and Protocols | Bluetooth 5.0, Bluetooth 4.2, Bluetooth 4.0 |
| Interface | F_USB 2.0 |
| Wireless Standards | IEEE 802.11ac/n/a 5 GHz IEEE 802.11n/g/b 2.4 GHz |
| Signal Rate | 5 GHz 11ac: Up to 867 Mbps(dynamic) 11n: Up to 300 Mbps(dynamic) 11a: Up to 54 Mbps(dynamic) 2.4 GHz 11n: Up to 300 Mbps(dynamic) 11g: Up to 54 Mbps(dynamic) 11b: Up to 11 Mbps(dynamic) |
| Reception Sensitivity | 5 GHz : 11ac HT80: -59.5 dBm 11ac HT40: -63 dBm 11ac HT20: -68 dBm 11n HT40: -70 dBm 11n HT20: -73 dBm 11a 54Mbps: -76 dBm 11a 6Mbps: -92 dBm 2.4GHz : 11n HT40: -67.5 dBm 11n HT20: -70 dBm 11g 54Mbps: -72 dBm 11b 11Mbps: -86.5 dBm |
| Wireless Modes | Infrastructure mode |
| Wireless Security | Support 64/128 bit WEP, WPA/WAP2, WPA-PSK/WPA2-PSK, 802.1x |
| Modulation Technology | DBPSK, DQPSK, CCK, OFDM, 16-QAM, 64-QAM, 256-QAM |
| Transmission Power | 5 GHz : 24 dBm(FCC) / 23dBm(CE) (EIRP) 2.4 GHz : 25 dBm(FCC) / 20dBm(CE) (EIRP) |
| Certification | CE, FCC, RoHS |
| Package Content | AC1200 Wireless Dual Band PCI Express Adapter Archer T4E Low-Profile Bracket Quick Installation Guide Resource CD |
| System Requirements | Windows 11/10/8.1/8/7/XP (32/64bit) |
| Environment | Operating Temperature: 0℃~40℃ (32℉~104℉) Storage Temperature: -40℃~70℃ (-40℉~158℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing |
